FM-Formula Mazda
Penske FM Rear Shock - Double Adjustable
FM Rear Shock - Double Adjustable - Penske *new in 08/2023 requires a 5" long spring
$745.00
Penske FM Front Shock - Double Adjustable
FM Front Shock - Double Adjustable - Penske *new in 08/2023 requires a 4" long spring
$745.00
Hyperco FM Front Spring - for Penske Shock
FM Front Spring | Hyperco Chassis Springs, 2.25" I.D. x 4" x 700 lb/in to be used with Penske Shock Update This is the recommended baseline spring for Formula Mazda with Penske Double Adjustable Shocks and Hoosier 35 B Compound Tires (43167)
$102.00
FM Rear Spring - for Penske Shock
FM Rear Spring | Hyperco Chassis Springs, 2.25" I.D. x 5" x 600 lb/in to be used with Penske Shock Update This is the recommended baseline spring for Formula Mazda with Penske Double Adjustable Shocks and Hoosier 35 B Compound Tires (43313)
$102.00
$278.00
Star Race Cars PFM | Sensor- Wheel Speed .700
$195.44 $175.75
GKN CV Boot & Cap | Lightweight Fast Boot
RaceCar Application: FMzR + FM FM - this is the lightweight option to replace the original 060-129. Replacing all (4) CV Joints (060-717) and CV Boots (060-718) equals a 2.85 lb reduction in rotating mass. GKN Motorsport S10 aerodynamic Fast Boot, with a zinc passivated steel outer and heavy duty rubber inner aero boot. TO BE USED WITH: 060-717 CV Joint - Lightweight
$38.00
CV Joint | Lightweight & Easy Motion
RaceCar Application: FMzR + FM FM - this is the lightweight option to replace the original 060-128. Replacing all (4) CVs and CV Boots (060-718) equals a 2.85 lb reduction in rotating mass. GKN Motorsport size 10 94mm lightweight CV joints. These plunging constant velocity joints feature a 94mm OD and and have been developed by GKN Motorsport to ensure easy rotational liner motion at for wheel or differential applications. With over 30 years of continuous development of GKN Driveline products, these GKN Motorsport plunging CV joints offer a significant weight reduction, cooler running temperatures and enhanced joint life through higher performance. TO BE USED WITH: 060-718 GKN CV Fast Boot
$155.00
Safety Harness
Formula belt with steel adjusters
$359.00
$55.00
$6.00
$14.00 - $28.00
$10.50 - $21.00
Shock Top Mount
Double Adjustable
$65.50 - $131.00
Motor Crank Pulley
Motor Crank Pulley
$49.50 - $99.00
Webster Gear Ratio : Webster 15/36 Gear Ratio
15/36 Webster Gear Ratio
$155.00 - $310.00
Webster Gear Ratio : Webster 24/24 Gear Ratio
24/24 Webster Gear Ratio
$155.00
$33.00
Braille Battery Mount - Braille G20
Aluminum Lightweight Race-Grade Battery Mount for Braille G20 Lithium Battery (battery not included) Secure your Braille G20 Lithium Battery with confidence using our Aluminum Lightweight Race-Grade Battery Mount. Engineered for durability and precision, this bracket is designed to securely mount your battery in your Formula Mazda FMzR or any race car. Made from high-quality lightweight aluminum, this mount ensures a snug fit while minimizing weight—essential for optimizing your car's performance on the track. Key Features: Precision Fit: Specifically designed for the Braille G20 Lithium "GREEN-LITE" Battery, providing a secure and stable mount in any race vehicle. Lightweight & Durable: Crafted from lightweight aluminum, it minimizes weight without sacrificing strength or reliability. Race-Grade Durability: Built to withstand the vibrations and rigors of racing, ensuring your battery stays securely in place. Versatile Use: Perfect for Formula Mazda FMzR, but compatible with any race car setup needing a secure battery solution. Upgrade your race car's setup with our Aluminum Lightweight Battery Mount and ensure your Braille G20 Lithium Battery stays safe and secure, lap after lap
$89.00
Charger - Braille Lithium Charger/Maintainer
The Braille Optimate TM-393 12V 6A sealed lithium battery saving charger and maintainer is ideal for 12V/13.2V LiFePO4 / LFP batteries. It features a power reset that rapidly re-energizes the battery and provides stable battery support during ECU programming / troubleshooting. The fully automatic multi-step program brings the battery safely to full charge. Weatherproof battery lead & battery clip set included. BENEFITS:• Revive low voltage battery safely from 1+ V• Rebalance Cells for optimal performance• Tests the battery State of Health (SOH)• Includes “Maintenance Charger Capability” where the battery voltage is tested every 30 minutes and the battery is only charged if needed• They are safe to leave on for prolonged periods• Eliminates risk of overcharging while prolonging life of battery
$158.00
Braille Battery - G20 - GreenLite Lithium Battery
At only 4.5 pounds, the GreenLite G20. The Braille Lithium Charger/Maintainer (sold separately) should be used in vehicles that are not driven regularly to offset parasitic draw. BENEFITS: • Quicker starting (a full volt higher than lead and less voltage drop during cranking)• Less horsepower draw from the alternator due to efficient charging (5 times faster than lead)• Can be used in "Total Loss" (no alternator) applications• Improved engine management & data logging performance (more stable voltage)• Lasts 3-5 times longer (especially under the harshest environments)• Much more reliable (less than 0.5% failure rate)• Significant weight savings. (up to 1/4 the weight)• Don’t self-discharge, so if the battery is disconnected (no draw or via power disconnect switch), they can sit for over a year and still have over 13 volts to start the vehicle.To get all these benefits in one simple step makes it a very cost effective upgrade!!
$428.00
Caliper Puck - Thermlock | Lightweight
RaceCar Application: FM FM - this is the lightweight option to replace the original which is no longer available. Replacing all (8) caliper pucks equals a 1.1 lb reduction in weight. Wilwood’s exclusive Thermlock Pistons provide the most effective thermal barrier available for minimizing heat transfer from the brake pads to the caliper body, seals and fluid. This innovative multi-part design incorporates a stainless steel shield and coated aluminum shell configuration that effectively retards heat transfer by at least 25 percent. This reduction in operating temperature eliminates seal crystallization and localized fluid boiling, which decreases distortion in the caliper body and piston bores, extending overall service life.
$59.00
Clutch Pressure Plate - Aluminum
SCCA Compliant as of 2022 - Lightweight Aluminum Pressure Plate - 7 lb weight reduction from original Pressure plate Recommended to Use - Pressure Plate Bolt Kit Torque Specs: 24 ft-lb
$520.00
MYLAPS (AMB) TR2 Transponder Direct Power + 1yr
Transponder including 1 Year Subscription The TR2 Transponder is the newest and most innovative transponder for car racing that can be powered by your vehicle battery and is replacing the X2 Direct Power Transponder. Reliable hardware, easy subscription management via Bluetooth and the Speedhive App, and flexible subscription options to fit your needs. Features: Can be powered by your vehicle battery (can NOT be used as rechargeable transponder) Easy buying and syncing your subscription with the Speedhive App Easy and free online access to your practice and race results via the Speedhive platform* Compatible with all MYLAPS (AMB) timing systems Accurate and reliable Unlimited warranty during active subscription (2 years warranty on TR2 Go Transponder)
$260.00
